900 Mhz Antenna Omnidirectional Omni Directional Rfid Antenna 915MHz Fiberglass Antenna 900-930MHz 7.5dB

Name: 900 Mhz Antenna Omnidirectional Omni Directional Rfid Antenna 915MHz Fiberglass Antenna 900-930MHz 7.5dB
Brand: Dongguan Leenz Electronics Co., Ltd
SKU: LZANT-10301-A
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Leenz

Certification: RoHs

Model Number: LZANT-10301-A

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 10

Delivery Time: 15 days

Payment Terms: T/T

Supply Ability: 5K per day

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                              900 mhz omni antenna, 900 mhz antenna omnidirectional, omni directional rfid antenna


Frequency:	900-930MHz	VSWR:	<2
Peak Gain:	7.5dBi	Impedance:	50

Frequency:	900-930MHz
VSWR:	<2
Peak Gain:	7.5dBi
Impedance:	50

Description

900 Mhz Antenna Omnidirectional Omni Directional Rfid Antenna 915MHz Fiberglass Antenna 900-930MHz 7.5dB

Outdoor Waterproof Omnidirectional Antenna IP67 RFID Antenna 915MHz Antenna Fiberglass Antenna 900-930MHz 7.5dB

1. Specification

A. Electrical Characteristics
Frequency	900-930MHz
S.W.R.	<= 2
Antenna Gain	7.5dBi
Efficiency	≈93%
Polarization	Linear
Horizontal Beamwidth	360°
Vertical Beamwidth	18°
Impedance	50 Ohm
Max Power	50W
B. Material & Mechanical Characteristics
Connector Type	N connector
Dimension	Φ20*1070±5mm
Weight	0.37Kg
Radome material	Fiberglass
C. Environmental
Operation Temperature	- 40 ˚C ~ + 80 ˚C
Storage Temperature	- 40 ˚C ~ + 80 ˚C
Rated Wind Velocity	36.9m/s
Lighting Protection	DC Ground

2. Antenna - S Parameter Test Data
2.1 VSWR

900 Mhz Antenna Omnidirectional Omni Directional Rfid Antenna 915MHz Fiberglass Antenna 900-930MHz 7.5dB 0

2.2 Total Efficiency & Gain:

Frequency(MHz)	900.0	905.0	910.0	915.0	920.0	925.0	930.0
Gain (dBi)	7.30	7.59	7.66	7.67	7.55	7.24	6.91
Efficiency (%)	91.87	97.79	98.64	97.95	94.69	89.09	84.96

2.3 Radiation Pattern

	3D	2D-Horizontal	2D-Vertical
900MHz
915MHz
930MHz
